Gases |
Liquids |
| Fluids |
Air, N2, O2, H2, He, Ar, and CO2 (Calibration by actual gas)
For other gases, consultation is necessary regarding whether
conversion conditions or calibration by actual gas is to be used.
* Optional: Scale indicating two types of fluids |
Standard fluid: Water
For other liquids, consultation is necessary regarding whether
conversion conditions or calibration by actual liquid is to be used. |
| Flow range |
0.5-5 ML/MIN to 3-30 L/MIN (See the Capacity Table below.)
* Optional: 0.5-3 ML/MIN |
0.5-5 ML/MIN to 0.1-1 L/MIN (See the Capacity Table below.)
* Optional: 0.5-3 ML/MIN |
| Accuracy |
FS±2% (Measurement point)
* Optional: FS±1% (Measurement point) |
FS±2% (Measurement point) |
| Proof pressure |
1.0 MPa for 100 ML/MIN or less
0.7 MPa for 5 L/MIN or less
0.5 MPa for 10 L/MIN or more |
1.0 MPa for 5 ML/MIN or less
0.7 MPa for 150 ML/MIN or less
0.5 MPa for 200 ML/MIN or more |
| Available scale |
10:1 * Optional: 20:1 |
| |
|
|
| |
|
|
| Materials |
SS |
BS |
| Body block |
SUS316 |
Brass |
| Tapered tube |
Pyrex®, glass |
| Packing |
FKM |
NBR |
| Float |
Pyrex, SUS316, glass |
| Protective cover |
Acrylic resin |
Temperature
resistance |
MAX60℃ |
| Connection end |
Rc1/4 (Standard); Rc1/8 (Optional) |
| |
| |
Gases |
Liquids |
| Fluids |
Air, N2, O2, H2, He, Ar, and CO2 (Calibration by actual gas)
For other gases, consultation is necessary regarding whether
conversion conditions or calibration by actual gas is to be used.
* Optional: Scale indicating two types of fluids |
Standard fluid: Water
For other liquids, consultation is necessary regarding whether
conversion conditions or calibration by actual liquid is to be used. |
| Flow range |
0.5-5 ML/MIN to 3-30 L/MIN (See the Capacity Table below.)
* Optional: 0.5-3 ML/MIN |
0.5-5 ML/MIN to 0.1-1 L/MIN (See the Capacity Table below.)
* Optional: 0.5-3 ML/MIN |
| Accuracy |
FS±2% (Measurement point)
* Optional: FS±1% (Measurement point) |
FS±2% (Measurement point) |
| Proof pressure |
1.0 MPa for 100 ML/MIN or less
0.7 MPa for 5 L/MIN or less
0.5 MPa for 10 L/MIN or more |
1.0 MPa for 5 ML/MIN or less
0.7 MPa for 150 ML/MIN or less
0.5 MPa for 200 ML/MIN or more |
| Available scale |
10:1 * Optional: 20:1 |
| |
|
|
| |
|
|
| Materials |
SS |
BS |
| Body block |
SUS316 |
Brass |
| Tapered tube |
Pyrex®, glass |
| Packing |
FKM |
NBR |
| Float |
Pyrex, SUS316, glass |
| Protective cover |
Acrylic resin |
Temperature
resistance |
MAX60℃ |
| Connection end |
Rc1/4 (Standard); Rc1/8 (Optional) |
| |
|
|
